bioTRANSOL

Transformer Oil

View PDF

Biotransol HF is a natural ester based dielectric fluid based on renewable vegetable oils. The fluid is readily biodegradable as per US EPA OECD 301B, environmentally friendly and non–toxic to aquatic life. The product is certified for its electrical and chemical properties by CPRI, a reputed laboratory in India for dielectric fluid testing. It is also tested & certified at the reputed laboratories of Intertek for its biodegradability & absence of aquatic toxicity.

Designed to have superior properties as compared to conventional mineral based oils, Biotransol HF is classified under K class based on its high flash and fire point. These characteristics make Biotransol HF the ideal choice for applications requiring high fire safety and environmental protection in case of accidents or spillages.

With over 40 years in the business of designing dielectric fluids for Transformers, Savita has crafted Biotransol, to not only protect the environment but also significantly increase the life and performance of your transformer. Biotransol is your ideal dielectric fluid in applications requiring higher levels of efficiency, safety and environmental consciousness.

Efficient

  • Faster moisture extraction from paper insulation while maintaining BDV, thereby increasing performance and extending life of your transformer.
  • Slows ageing of transformer by enhancing life of solid insulation material.
  • Transformer load can be enhanced as a result of diminished paper ageing.
  • Reduces maintenance time and cost.
  • Less consumption of fluid relative to conventional oils.
  • Lower insurance premiums as a result of superior safety properties.
  • Lowers cost of clean-up and impact in case of accidental spillages.
  • Delays asset replacement and capex by prolonging the life of an aged transformer after Retrofil.

Safe

  • With a high Fire and Flash Point (>320°C, > 300°C), Biotransol significantly reduces risk of ignition and fire in case of accident.
  • Enhances safety for workers during installation, maintenance and condition monitoring.
  • Minimum damage in the event of spillage, as a result of its biodegradable nature.

Eco-Friendly

  • Designed from entirely renewable sources.
  • Reduces carbon footprint by being completely biodegradable.
  • Non-toxic and eco-friendly to the environment and aquatic life.

TECHNICAL DATA OF BIOTRANSOL-HF

  Standard Test Methods ASTM D6871 IEC 62770 Biotransol HF
Property ASTM ISO/IEC New unused fluids New unused fluids Typical
PHYSICAL PROPERTIES
Colour D1500 ISO 2211 ≤ 1.0 0.5
Flash Point COC (℃) D92 ISO 2592 ≥ 275 320 - 330
Fire Point (℃) D92 ISO 2592 ≥ 300 > 300 350 - 360
Pour Point (℃) D97 ISO 3016 ≤ -10 ≤ -10 -15 to -18
Density at 20℃ (g/cm3) ISO 3675 ≤ 1.0 0.92
Viscosity (mm2/sec) D445 ISO 3104
100℃ ≤ 15 ≤ 15 7.2 - 8.5
40℃ ≤ 50 ≤ 50 32 - 35
Visual Examination D1524 IEC61099 9.2 bright and clear clear, free from
sediment and
suspended matter
bright and clear
ELECTRICAL PROPERTIES
Dielectric Breakdown (kV) 2.5mm gap IEC 60156 ≥ 35 70
Gassing Tendency (mm/min) D2300 ≤ 0 -6.6
Dissipation Factor
25℃ (%) D924 ≤ 0.20 0.15
90℃ (tan δ)   IEC 60247 ≤ 0.05 0.02 - 0.03
100℃ (%) D924 ≤ 4.0 2.15
CHEMICAL PROPERTIES
Corrosive Sulfur D1275 IEC 62697 non-corrosive non-corrosive non-corrosive
Water Content (mg/Kg) D1533 IEC 60814 ≤ 200 ≤ 200 < 50
Acid Number (mg KOH/g) D974 IEC 62021.3 ≤ 0.06 ≤ 0.06 0.03
PCB Content (mg/Kg) D4059 not detectable free from PCBs not detectable
Oxidation Stability (48hrs, 120℃) IEC 61125C
Total Acidity (mg KOH/g) IEC 62021.3 ≤ 0.6 0.1
Viscosity 40℃ (mm2/sec) ISO 3104 ≤ 30%
increase over initial
17.8
Dissipation Factor at 90℃ (tan δ) IEC 60247 ≤ 0.5 0.2
Biodegradation OECD 301 readily biodegradable readily biodegradable
